32" Complete Go Kart Rear Live Axle Kit with 4.10-6" Wheels Tires& Brushless 48V 1800W Electric Motor Kit Controller & 4 Pack 12V 12Ah Battery Set for DIY ATV Quad Buggy Drift Trike

Motor Specification:Style: striae & RoundOperating voltage: 5VAdjustment range: Minimum ?1.0V; highest ?4.0VFunction: high, medium and low grades governorElectric brushless Motor:Type : Brushless DC MotorOutput Power: 1800WVoltage : 48VMax Speed: 4500rpmThe Sproket installed on the motor : T8F 9T420 Rear chain Sprocket For Pit Dirt Bike ATV Quad Buggy Go Kart Mini Bike420-48T-51mm: Central hole diameter: 51mm420 10T Motor Sprocket: Inner hole Size: Approx. 10x8.5mm420 100 Links ChainRear Axle Specification:High-Strength Chrome Axle: 32-inch (810mm) chrome axle, designed to support over 500lbs, ideal for various DIY projects including go-karts, ATVs, and quad bikes.Adaptable Sprocket Options: Standard package includes a 420 37T sprocketEfficient Brake Assembly: Features a 190mm brake disc paired with a master cylinder, ensuring reliable and efficient stopping power for your vehicle.Comprehensive Wheel Setup: Includes four 13x5.00-6 tubeless wheels with rims, offering compatibility with a wide range of vehicles from drift trikes to buggies.Complete Steering System: Comes with a front steering wheel, gear rack assembly, wheel hubs, and steering spindles, providing a full setup for enhanced maneuverability and control.Key Features:Versatile Use: Suitable for a broad range of DIY vehicles, including go-karts, ATVs, drift trikes, golf carts, 4 wheelers, tricycles Quads, and buggies.Easy Installation: Designed with simplicity in mind, this kit allows for straightforward assembly, making it accessible for both novices and experienced builders.Durability and Performance: Built with high-quality materials, ensuring long-term durability and optimal performance in various conditions.1 x 32-Inch High-Strength Chrome Axle KitAll-In-One Axle Kit: Includes axle, brake disc, 1" pillow block bearings, and 4-bolt hub.Size Specifications: Axle length of 32" (810mm) with a 1" diameter, and a thick part of 1 3/16" (30mm).Versatile and Robust: Ideal for DIY go karts, ATVs, quads, trikes, and golf carts.Wheel Fit: Compatible with 6"-10" wheels, supporting over 500lbs.Engine Flexibility: Suitable for both vertical/horizontal engines and electric motors.1 x Front Steering Wheel and Gear Rack AssemblyHigh-quality and durable constructionDesigned for DIY Go Kart, ATV, Buggy electric, or 110cc, 125cc, 150cc vehiclesAdjustable shaft with a length range of 9.75 inches to 12.5 inchesIncludes tie rod, rack, and adjustable shaftProvides end-to-end length range of 33 inches to 35 inchesPackage includes : Rear Axle Kit + Pair of pillow blocks+ Brake assembly+ +420 37T sprocket + 4x 4.10-6" Wheels + 4 and 3 bolt wheel hubs + Front wheel hubs+Front Steering Spindles+Front Steering Wheel and gear rack assemly+ Motor + 420 10T motor sprocket + 420 48T rear chain sprocket + 420 100 links chain + speed controller + key switch+ charging port+ power indicator + wiring harness+ terminal block+ foot pedal + throttle grips + forward reverse switch +circuit breaker + 3 speed toggle switch + 4 x 12v 12ah 6-dzm-12 Battery + 48V battery Charger

• Axle overall length 32 inch (810mm), 1" in diameter and the thickest part of the axle is 1 3/16" (30mm)
• Motor Input Voltage: 48V DC, Output Power: 1800W, Rated Current: 33A, Rated Speed: 4500 RPM, Maximum Speed: 5200 RPM, Sprocket: T8F-9T, Maximum Current: 37.5A.
• The running direction of the motor can be changed by changing the wiring between the motor and the controller (reverse-counterclockwise) : Step 1: 3 thick yellow, green and blue wires (phase wires) : Controller to the motor - yellow to yellow, blue to green, green to blue; Step 2: 6 Hall Wires: Controller to the motor - blue to yellow, other unchanged.
• Chain Sprocket: 420 37 Teeth 48mm hole diameter , Brake Disc Diameter: 190mm(7.5")
• It is suitable for go karts, golf carts, scooters, e-bikes, ATVs, motorized bicycles, mopeds, mini bikes, pocket bikes,E Tricycle, 4 wheeler, Quad, Buggy, Drift Trike
• Package includes : Rear Axle Kit + Pair of pillow blocks+ Brake assembly+ +420 37T sprocket + 4x 4.10-6" Wheels + 4 and 3 bolt wheel hubs + Front wheel hubs+Front Steering Spindles+Front Steering Wheel and gear rack assemly+ Motor + 420 10T motor sprocket + 420 48T rear chain sprocket + 420 100 links chain + speed controller + key switch+ charging port+ power indicator + wiring harness+ terminal block+ foot pedal + throttle grips + forward reverse switch +circuit breaker + 3 speed toggle switch + 4 x 12v 12ah 6-dzm-12 Battery + 48V battery Charger
