All-in-1 RGB CGA EGA VGA Component YCbCr Video to VGA 1980x1080 Video Scaler Converter

This RGB and VGA to VGA converter scaler can up convert the legacy CGA, EGA, VGA or 480i 576i component YCbCr video to selectable VGA output resolutions up 1920x1080 pixels or 1080p for display on LCD monitor, projector or LCD TV. Great replacement display solution for those older CGA type and EGA type RGB equipments or analog video devices with 480i 576i component video YCbCr outputs. 4 selectable video inputs, CGA, EGA, VGA and component RGB video input. 5 selectable VGA output resolutions, 640x480, 800x600, 1024x768, 1366x768 and 1920x1080 pixels. This converter uses 15-pin VGA connector for both CGA input and component video input. The DB 9-pin to VGA 15-pin adapter cable for CGA input is sold separately. 15kHz CGA and EGA RGB To VGA Converter Scaler Those arcade game boards or older gaming computers that can output in legacy CGA or EGA type RGB video equipments can be converted to high resolution VGA video. The CGA input video supported is 640 x 200 pixels at 60Hz while EGA video supported is 640 x 350 pixels at 85Hz. The CGA and EGA input will be auto-detected and can be either RGBHV or RGsB (Sync-on-Green). Component YCbCr Video To VGA Converter The component RGB video input will be auto-detected and can be either RGBHV or RGsB (Sync-on-Green). The component video input adapter cable is included in the package. Computer VGA To VGA Up-Scaling And Down-Scaling The RGB and VGA input support range of this RGB converter is from 640x200 to 4K or 4096x2160 pixels. Auto And Manual Screen Position Adjustment For Video Output This RGB video scaler has auto and manual adjustment of the video screen position through using the horizontal/vertical position function adjustment and phase/clock setting in the on-screen system menu.

• Compatible devices: Television
• Item weight: 1.3 pounds
