LED Dimmer V4 12VDC 24V 36V 48V 4-Channel Push Button dimmer Switch PWM 2.4G RS6 Control Single Color LED Light Strip(RS6 Remote Only)

Outlet & Switch CombosLED Dimmer V4 12V DC 24V 36V 48V 4-channel push dimmer switch PWM 2.4G RS6 control single color LED light stripfeatureWith 2.4G single zone or multi-zone single color,Dual color and RGB/RGBW remote control.Up to 10 remote controls can be connected to one controller.4096 levels of smooth dimming, no flicker.When used with RGB/RGBW lights, there are 10 built-in dynamic modes.Include jump or gradient styles.Automatic transmission function: the controller automatically transmits signals toAnother controller, the control distance is 30m.Synchronize across multiple controllers.The light on/off fade time is optional for 3 seconds.Connecting external buttons can achieve on/off and 0-100% dimming functions.Overheating/overload/short circuit protection, automatic recovery.4-channel monochromatic dimming is possible using V4 and RS6(Receiver) Specifications:Product name: 2.4GLED dimmer (four channels)Receiver: LSD-V4(receiver and transmitter): LSD-V4+RS6;Input voltage: 12V 24V 36V 48VDCInput current: 20.5AOutput current: 4 channels, 5A/channelOutput power: 12V, maximum 240W; 24V, maximum 480W; 36V, maximum 720W; 48V, maximum 960WOutput type: constant voltageInput signal: 2.4GHz + Push DimControl distance: 30m (barrier-free space)Dimming gray scale: 4096 (2^12) levelsDimming range: 0 -100%Dimming curve: logarithmicPWM frequency: 1000Hz (default)Size: L175×W45×H27mmnotes:LSD-V4+RS6 (4-channel dimmer)Push dimming controlThe 4 buttons have 4-channel dimming function by default.Short press: Turn each channel on or off.Long press (1-6 seconds): Press and hold to perform stepless dimming of each channel. Every time you press and hold, the brightness will change in the opposite direction.Dimming Memory: When turned off and on again, the light returns to its previous dimming level.You can also press and hold the button and matching button at the same time to select 4 light types.Each light type has different key functions.Press and hold the 1 key and the Match key for 2 seconds to set to 4-channel monochrome type (default).Press and hold the 2 key and the Match key for 2 seconds to set the two-color type.Press and hold the 3 key and the Match key for 2 seconds to set the RGB type.Press and hold the 4 key and the Match key for 2 seconds to set the RGBW type.At this time, if the light type has been set to Bi-Color, RGB or RGBW, matching the remote will not change the light type.If you want to cancel the light type setting, please press and hold the Match button for 10 seconds to restore the factory .=========Features: LED dimmerModel: 2.4G LED controllerCertification: EMC, CCC, FCC, UL, GS, ROHS, ceMaterial: ABSmaximum. Load power: 960Product Type: DimmerOrigin: Mainland ChinaOutput signal: (2.4GHz)Remote control distance: 30 metersInput voltage: DC12V 24V 36BV 48VOutput current: 4CH, 20AOutput power: 240-960WSwitch: 2.4G 4 Channels for: Monochrome LED StripsFeature 1: 2.4G LED dimmerFeature 2: LED dimmerFeature 3: LED dimmer 12VFeature 4: LED dimmer 24VFeature 5: LED dimmer 36VFeature 6: 4-channel dimmerFeature 7: 48V LED dimmerOutput type: constant voltageInput signal: 2.4GHz + Push DimDimming gray scale: 4096 (2^12) levelsDimming range: 0 -100%Dimming curve: logarithmicPWM frequency: 1000Hz (default)
